Timber panel

Precision prefabrication down to the millimetre

Timber panel construction revolutionised timber engineering. Even today, many designers are not fully aware of the possibilities offered by this construction method. Increasing requirements for thermal and acoustic performance, the growing importance of airtight building envelopes, and the advantages of fast, dry construction have contributed to the widespread use of timber panel construction.

Module T08

Wall panels can be designed using Module T08 in accordance with DIN EN 1995-1-1:2010-12 in conjunction with the applicable National Application Documents. The verification method follows DIN EN 1995-1-1:2010-12, Section 9.2.4.2 – Method A.


SHEATHING

The following material is available:

  • OSB panels, sheathing on one side


VERIFICATIONS

The following verifications are performed:

  • Load-bearing capacity of the fasteners
  • Racking resistance of the wall panel
  • Verification of buckling due to shear in the sheathing
  • Load-bearing capacity of the sheathing
  • Verification of the tensile anchorage of the end studs

Timber panels

Applications

Wall panel, one-sided
Report – wall panel, one-sided
pdf

Integrated connectors

Hold-down anchors
HD hold-down anchor
Hold-down anchors
Hilti HCW L 40x295 M12
Shear connectors
Hilti 37x45 M12

Design basis

The timber panels are designed in accordance with DIN EN 1995-1-1:2010-12 in conjunction with the applicable National Application Documents. The verification method follows DIN EN 1995-1-1:2010-12, Section 9.2.4.2 – Method A.

Practical knowledge

Lateral stability of timber buildings

How does a wall panel behave under horizontal loading?



Learn how lateral stability works in timber buildings. We explain the individual components of a timber panel and describe the structural behaviour of the panel as a composite structural element.



This handbook is continuously being expanded. We welcome your questions on lateral stability and bracing systems in timber construction.




Go to handbook


Module pricing (per month, excl. VAT)

Free

0 €
per month

Unlimited testing

You can test Module T08 Timber Panel free of charge and without obligation.
